Fabricante de paneles sándwich de espuma XPS de fibra de vidrio

Aplicación

Automotive sector:

Construction Sector:
Suitable for insulation layers in building roofs, wall panels, and exterior walls. Also applicable for farms and mobile homes. Enhances waterproofing, corrosion resistance, and offers excellent thermal insulation with improved soundproofing.

Marine Sector:
Used in manufacturing ships, pontoons, yachts, and fishing vessels. XPS foam features low density for stability, while its closed-cell design effectively prevents moisture penetration.

Industrial Applications:
Suitable for cold storage warehouses, equipment insulation casings, and thermal insulation applications. We offer customized fire-retardant properties to reduce costs and emissions. Extensive CNC machining capabilities are available.

Custom Fiberglass XPS Sandwich Panels

Fiberglass XPS sandwich panels offer numerous customization options. Below are the custom features we support:

Dimension Customization:

• Fiberglass skin thickness: 0.6–5mm
• XPS foam thickness: 10–120mm, with densities ranging from 70–205kg/m³
• Overall dimensions: Length ≤11.8m, width ≤3.2m

Appearance Customization:

• Fiberglass skin options: Zhanhe fiberglass woven fabric
• Surface textures: Checkered, bubble, fabric patterns, etc.
• Surface finishes: Matte, glossy, white, black, gray
• Special treatments: UV-resistant gel coating, flame-retardant process (adding flame retardants to achieve fire ratings B1/B2/B3). Our products contain no asbestos.

Customization Process:

Our customization process is straightforward. Clients provide specific requirements, including application scenarios and parameter specifications. Our team delivers precise evaluations and tailored solutions. After manufacturing samples, we conduct testing to ensure compliance with client specifications—such as fire ratings and waterproof performance—before proceeding to mass production. Our experts provide full support throughout order tracking and production. We strive to deliver the desired value and performance while offering the highest level of service.

Estructura del XPS de fibra de vidrio

Espuma XPS

XPS son las siglas de Extruded Styrene Foam Board, que tiene buenas propiedades aislantes y se utiliza para el aislamiento térmico. Es un material rígido de celdas cerradas que no absorbe agua y tiene una larga vida útil.

Chapa FRP

El FRP es un excelente material de alto rendimiento, compuesto por refuerzo de fibra de vidrio. Tiene un alto rendimiento, alta resistencia y resistencia a los rayos UV.

Special Processing

CNC Machining: We offer CNC equipment for drilling, cutting, engraving, and other operations on sheet materials. This enables the creation of various shapes and functionalities. We possess multiple imported CNC machines.

Reinforced Structures: For applications in refrigerated trucks and RVs, we embed high-strength materials like aluminum tubes or FRP tubes within the sheet material. This significantly enhances its bending resistance and load-bearing capacity, ensuring minimal deformation over extended use.

Tratamiento de la superficie: We enhance performance through various coatings and processes, including UV-protective coatings and flame-retardant treatments, which modify material properties.

Composite Process: Our fully automated vacuum composite line bonds fiberglass and XPS foam with excellent adhesion, improving overall performance.

Advantages of Glass Fiber XPS Foam Sandwich Panels

• Superior Thermal Insulation: With thermal conductivity as low as 0.024–0.034 W/m·K, it effectively reduces energy consumption. Ideal for refrigerated transport and building insulation, maintaining stable temperatures.
• Lightweight and Easy to Process: Density ranges from 35–45 kg/m³, facilitating cutting and installation. Reduces vehicle weight, enhancing transport efficiency and operational convenience.
• Waterproof and Corrosion-Resistant: Closed-cell structure with water absorption below 1%, resisting moisture and chemical corrosion for long-term use in marine or industrial environments.
• Fire-Resistant and Durable: Meets Class B1 fire rating, withstands temperature fluctuations from -50°C to +80°C, and boasts a service life exceeding 20 years.
• Environmentally Sustainable: Recyclable material free of asbestos components reduces carbon emissions, meeting modern eco-standards for green building projects.
• High Cost-Effectiveness: Offers 20% cost savings compared to traditional materials. Lightweight design lowers maintenance and transportation expenses, enhancing overall economic efficiency.

Aplicación del panel XPS de fibra de vidrio

Este producto es ideal para aplicaciones que requieren propiedades de aislamiento térmico e impermeabilización. Por ejemplo, aislamiento de interiores, aislamiento de edificios, aislamiento de vehículos, etc.

• Camión frigorífico
• Remolques frigoríficos
• Paneles murales para cámaras frigoríficas
• Casas móviles
• Caravanas
• Interiores de yates y aviones

Parámetros del producto

Custom Processing

Embedded Reinforcement Structures

To enhance strength and functionality, reinforcement materials can be embedded within composite panels. Options include plywood, aluminum alloy profiles, GRP tubes, steel structural components, and more.

Multi-Material Composite Processing

We specialize in composite processing of materials such as FRP, CFRT, and foam cores, delivering superior performance while meeting diverse application requirements.

High-Precision CNC Machining

Advanced CNC machining centers enable high-speed precision cutting, complex contour milling, drilling, and more.

Edge Processing

Edge finishing and connector integration are performed according to specific requirements. Services include edge wrapping, chamfering and grinding, waterproofing, and embedded nuts.
